ZERO-LINE PRO EDGEBANDING

Tested on Laser, Hot-Air, Near-IR, and Plasma applications; our specially formulated functional layer produces an invisible joint which is one of the best in the industry. Our Edgebanding comes in two forms: Zero-Line Pro which is co-extruded from PP. And Zero-Line Pre which is preglued on ABS.

Product
Zero-Line Pro Edgebanding
Application
Laser, Airtec, Hot-Air, Plasma, Near-IR, other zero-glue applications
Available Thickness
Min. thickness: 1,2mm, max: 3mm.
Available width
Jumbo roll between 9mm and 250mm
MOQ for Pro (Co-extruded)
200kg from PP
MOQ for Pre (Pre-glued)
2100mt per color in 22mm

Our Zero-Line Pro Edgebanding can work with all machines.

HOTAIR APPLICATION

Our Zero-Line Pro edgebanding works well with hotair and other similar technologies. You can see technical details for each machine:

HOMAG AIRTEC	Line speed = 10 m/min	Line speed =20 m/min
Nozzle Temperature	460 - 510 °C	490 - 530 °C
Nozzle Pressure	1.5 - 2.5 bar	2.5 - 3.5 bar

BIESS AIRFORCE	Line speed, up to 18 m/min (Akron)	Line speed, up to 30 m/min (Stream)
Nozzle Temperature	460-510 °C	560-610 °C
Air Volume	1000 - 1200 nl/min	1000 - 1200 nl/min

HEBROCK AIRTRONIC	Line speed = 10 m/min
Temperature	460-510 °C
Air Volume	460-500 nl/min

SCHUGOMA KANTENKING	Line speed, up to 25 m/min
Temperature	310-350 °C
Air Pressure	5-6 bar

LASER APPLICATION

Initially, this was the most common zero-line application. But due to its price, companies now prefer hotair technology over this.

Below, you can find laser application values for our Zero-Line Pro Edgebanding.

Color	E (J/cm 2 )
White	24-26
Light Grey	21-23
Black	15-17
Beige	23-25
Brown	20-22
Dark Brown	18-20
Dark Grey	19-21

Variable from 15-26 based on the color

INFRARED APPLICATIONS

Our functional layer works with all zero-glue line technologies, Infrared application included. One of our testers commented as below:
"From my point of view the material was good for the strength and optic."

If you require a sample for testing, please just get in touch with us.

Any color is possible

There is no limit to the colors that we can match in Zero-Line Pro. It is made from PP.

Watch our video to see this product in details...

How can we help?

Zero-Line Pro edgebanding is the most complicated product in our portfolio. And we have worked hard to make sure that it works well with all machines.

Please get in touch with us for sample and for more information.
